WiFi remote picture transmission control module track/wind power station wireless transmission, in view of the complexity of site monitoring in the field of industrial construction, how to ensure the construction safety, promote civilized construction, improve production efficiency is the primary task of the construction unit and superior authorities. In order to promote production safety, it is necessary to carry out comprehensive wireless coverage on the production vehicle track and conduct comprehensive monitoring on the driving of production vehicles. WiFi remote picture transmission control module provides wireless transmission scheme planning and equipment technical installation for this project.
WiFi remote image transmission control module mainly describes the coverage of each point:
Point A covers the track area of Car 1 and Car 2. At the same time, car 1 and car 2 themselves have the docking function in the process of driving, and connect the signal of point a at the same time, so that any position of the track can be connected with point a.
Point B and point C cover two layers of orbit simultaneously. Because of a high wall, there are two devices here for signals to cover both directions of the same track. At the same time, car 3 and car 4 remain connected at all times, connecting B or C at the same time, and the car traveling on the track can transmit the signal to the monitoring room.
Point D covers the track area where car 5 and car 6 travel. At the same time, car 5 and car 6 themselves have the docking function in the process of driving, point D signal, so that any position of the track can be connected with point D.
Point E covers the track area of Car 7 and Car 8. At the same time, car 7 and car 8 have the docking function in the process of running, and connect the signal of point E, so that any position of the track can be connected with point E.
WiFi remote image transmission control module is a kind of exquisite AD hoc network efficient digital wireless transmission. It has the type approval certificate of radio transmission equipment certified by the Ministry of Industry and Information Technology. It is suitable for wireless AD hoc network connection service in harsh field environment, providing high bandwidth network connection and multimedia IP for deploying enterprises and industrial users. For data transmission requirements, the WiFi remote picture transmission control module can automatically select the best transmission path for link. You can complete a few simple setup steps without complicated configuration. You can connect quickly in the mobile state or automatically select the best transmission path in the fixed link. Not only suitable for network transmission, but also suitable for large-scale IP monitoring requirements. The device uses an external antenna design. According to different application environment and distance requirements, high gain external antennas in the corresponding frequency band can be matched, such as dual-polarized MIMO omnidirectional antenna, directional MIMO antenna with higher gain, plate antenna, disk antenna, etc. The suitable antenna can be selected to make the distance more than 20km.
WiFi remote image transmission control module supports a series of outdoor industrial wireless bridging devices BaseStation mode, CPE mode, P2P(Bridge) mode, MESH coordination between different modes can achieve different effects, can do point to point transmission, point to point transmission, Mesh fast AD hoc network transmission mode. In Mesh mode, any networking without center can be realized among the same group of devices, and the selection of device frequency is wider. The 5G frequency band ranges from 4800 MHZ to 6275MHz. The WiFi remote image transmission control module is easy to operate, which eliminates the complicated operation mode, makes debugging more convenient, facilitates rapid deployment, and is very suitable for the quick startup of engineers and technicians. When there is no mains electricity in the field, it can be flexibly combined with battery, solar energy, wind power and other power supply modes.
WiFi remote image transmission control module main features
Operation mode: BaseStation mode, CPE mode, P2P(Bridge) mode, MESH mode
Supports 5.8G and 2.4G network transmission
Supports IEEE802.11n and IEEE802.11a standards
Up to 266dBm, receiving sensitivity is -95dBm
Working in 5.8G, 2.4ISM band (Optional)
Support point - to - point, point - to - multipoint, Mesh AD hoc network wireless transmission
Wide voltage input is supported
Supports the STP spanning tree protocol
Support SNMP
The frequency selection is wide, from 4800~6275MHz
After our company's technicians guided the planning of installation points on site, the wireless transmission signal coverage project of WiFi remote picture transmission control module was successfully completed. After testing, the project side is very satisfied with the wireless signal transmission effect of each point on the track. Through the application of wireless transmission system of WiFi remote picture transmission control module and the organic cooperation of on-site safety management personnel, the project side can better play a supervisory role to ensure safe production.
WiFi remote picture transmission control module remote wireless transmission case of wind power station, wind power plant construction process safety monitoring project due to the construction site environment is bad, the benefit of the country, energy saving and emission reduction. All this is there for all to see. This project adopts the microwave wireless transmission technology of WiFi remote picture transmission control module, which has high bandwidth, remote and remote inspection and monitoring. The project also adds wireless WiFi coverage function equipment, mainly to deal with the dilemma of no network and no signal in the mountain area, and to provide the basic guarantee of external contact and emergency rescue for the wind farm staff.
In the process of transporting the equipment, the nearly 10 kilometers of winding and steep mountain road driving from accommodation to the workplace was terrifying. After two months of the rainy season, the mountain roads were muddy and muddy, especially when transporting materials, and I was worried that cars would slide down the hill. Several times, the wheels fell into the mire. With the help of several masters, every time they were pushed to the top of the hill, occasionally they would be pushed out of the mire in half an hour. Countless times, the bottom of the car was scratched by stones. Fortunately, I worked hard to finish the task and was very happy.
In order to observe the work progress and infrastructure level of employees in real time, five high-definition ball machines, five digital wireless, five digital wireless WiFi coverage, 10 WiFi remote picture transmission control modules wireless microwave networking and two mobile military stations were built. In order to record footage and Internet communication effectively in blind workplaces, mobile military stations better take care of workers' rights.
After the completion of the project, through repeated field tests, the equipment can adapt to the harsh local natural conditions, timely and stable front-end video images back to the monitoring center. The wireless transmission equipment is well connected, and the WiFi remote image transmission control module can return monitoring images and other data acquisition in real time. The total bandwidth measured can reach more than 100MB, fully meeting the needs of customers.
