UWB module UWB positioning accuracy builds a new benchmark for 5G+UWB smart power plant World Expo.In order to promote the construction of smart power plants and use 5G to drive UWB location empowerment, a dual-network integrated safety management solution was introduced to achieve the safety goals of power plant construction and create a new benchmark for 5G+UWB module smart power plant demonstrations.
Safe production is the basic premise for the continuous operation of power generation enterprises. Emergency handling, major hazard control and maintenance area management are important dimensions that reflect the safety management level of power generation enterprises.
In order to improve the level of safety management, the power plant adopts informatization, mobile and intelligent technology to realize the real-time, interactive and active on-site safety control. Through active early warning and monitoring of the on-site risk environment, comprehensive on-site safety management of pre-event prevention, in-event monitoring, and post-event traceability can be realized, avoiding accidents to the greatest extent, and ensuring that production operations can be efficiently and smoothly implemented in accordance with the two-invoice specification.
Empowering 5G to drive the location
The whole solution uses 5G network as the transmission medium of UWB module positioning data, and realizes online monitoring and real-time intervention of major operations and high-risk operations through the real-time position and movement trajectory of the high-precision positioning data management system to ensure that the behavior of on-site personnel is controllable and location are visible.
As an important link in the construction and connection of the Taizhou Power Plant of the National Energy Group, 5G has achieved full coverage of the 5G network in the entire power plant area through the joint construction and sharing of 5G by telecom operators. The 5G network is used to transmit the positioning data collected by each switch to the user center, and the internal data separation is realized through edge computing equipment to ensure data security and effectively reduce network delay; at the same time, the integrated construction of 5G + UWB positioning accuracy dual network greatly reduces aggregation. The complexity of line design provides a network channel for multi-device connection, saving a lot of investment and maintenance costs for optical fiber lines and equipment.
According to the construction goal of the national energy power plant, the high-precision positioning management system based on UWB module positioning technology provides powerful data support for the information management and intelligent control of the power plant.
Personnel intelligent management
Based on the UWB module positioning technology, it can accurately locate the location of the on-site personnel in the power plant, and query the activity trajectory and basic information of the on-site personnel on the 3D map in real time; support personnel attendance, operator statistics, on-the-job status query, inspection control, etc.
area operation control
Power plant areas are divided by virtual electronic fences, such as operator count, high-risk operation areas, and area access permission settings. Integrate with the two-ticket system, connect the access control in the area, and automatically authorize and reclaim permissions according to the operation start time and end time. At the same time, regional risk information can be pushed to relevant operators for risk pre-control.
Security early warning control
Electronic fences are set up in high-risk and accident-prone areas, including rapid evacuation, intrusion alarm, overtime, etc. Once the on-site personnel violate the regulations, a remote alarm prompt will be issued; in an emergency, the on-site personnel can also send an emergency alarm signal; combined with the video surveillance system, it supports the rapid call of the camera.
The National Energy Power Plant Project has created a new demonstration application of 5G+UWB positioning accuracy smart power plant construction, witnessed the rapid development of the 5G+UWB industry, and will create a new blueprint in the field of location services with industry partners.
State Grid introduces UWB module UWB positioning accuracy new technology to escort the power consumption of the World Expo
The second China International Import Expo ended successfully at the Shanghai National Convention and Exhibition Center. The Expo attracted more than 3,800 enterprises from 181 countries, regions and international organizations to participate in the exhibition, and more than 500,000 domestic and foreign professional buyers attended the conference, far exceeding the first conference.
This year's World Expo has achieved fruitful results in transaction procurement. On an annual basis, the accumulated intentional transactions amounted to US$71.13 billion, an increase of 23% over the first World Expo. Behind the realization of these figures, there is a group of behind-the-scenes operation and maintenance support units sticking to their posts, silently escorting the smooth progress of the exhibition.
As one of the important security units of the World Expo, State Grid Electric Power Company provides power security services for the World Expo to ensure the safety and reliability of the power supply during the World Expo.
State Grid Power has achieved success in the power work of the 2nd World Expo, which is closely related to advanced technologies such as the Internet of Things and artificial intelligence. State Grid Shanghai Power actively promotes power system interconnection, human-computer interaction, comprehensive perception of construction status, efficient information processing, The application of convenient and flexible power Internet of Things. The trajectory tracking of precise positioning and high-precision positioning technology has also become one of the core technologies of the power Internet of Things. UWB positioning management system provides application-layer positioning data services for State Grid power substations, helps State Grid operation and maintenance personnel to realize remote control of on-site inspections, and jointly escort the World Expo.
Substation Inspection FAQ
The daily equipment inspection of the substation is not only the basis for ensuring safe production, but also the key to ensuring the safe operation of the substation. At present, the traditional inspection mode cannot track whether the inspectors arrive at the checkpoints according to the designated route, and monitor the dwell time of the inspectors at each checkpoint. Therefore, how to improve the work efficiency of equipment inspection and effectively supervise the management of inspectors is the goal of substation operation management.
UWB positioning accuracy technology makes inspection traceable
Based on the UWB ultra-wideband positioning technology, the positioning algorithm is used, and the positioning tag is used to transmit pulse signals to the positioning base station.
Smart Check Control
Through the UWB positioning management system to accurately locate the on-site inspectors, and upload the collected location data to the large screen of the control center, it is possible to track whether the inspectors arrive at the inspection point according to the designated route, monitor the time of the inspectors arriving at each inspection point, etc., and judge the inspection. Whether the personnel comply with the inspection requirements, realize the visualization and intelligence of the inspection process, and improve the management efficiency of the Expo power protection work.
Intelligent inspection robot management
In order to meet the high-standard requirements for power security during the Expo, State Grid Power has equipped the power grid in the region with intelligent inspection robots, and conducted 24-hour continuous inspections on the status indicators of equipment such as the distribution station room and switch room. Operation and maintenance managers collect and integrate the location data of intelligent inspection robots based on UWB positioning technology, conduct multi-dimensional analysis combined with power grid operation data, predict the operation trend of various equipment, and complete processing before faults or even defects occur.
Manage visitors
State Grid Electric Power Substation, as one of the visiting sites of the Expo, uses UWB positioning technology to accurately obtain the location of visitors and trace the activity of visitors. When a visitor enters a dangerous area, the system will automatically issue a warning to remind people to leave the dangerous area.
At present, many power companies have established ubiquitous power IoT sensor laboratories. While ensuring the low cost, low power consumption, high speed and maintenance-free of IoT sensors, it speeds up the physical operation and truly brings out the management benefits of the IoT. UWB module UWB positioning accuracy keeps up with the development wave of the ubiquitous power Internet of Things, continuously optimizes the industrial layout, and explores more innovative business applications suitable for the construction of the ubiquitous power Internet of Things.
